26 April 2018

USB-to-UART/I2C/SMBus/SPI Protocol Converters from Microchip

New Microchips ICs providing USB connectivity tо systems having UART, I2C or SPI communication interfaces!





Features such as integrated USB termination resistors, internal oscillator, ADCs, DACs and GPIO offer system designers needed flexibility and help minimize external component count. These products are well suited for small embedded Linux®/Android systems, industrial control and medical systems. As well as consumer applications including digital cameras, set-top boxes, MP3 players, multi-meters and data loggers.

MCP2200 – USB-to-UART Protocol Converter

The MCP2200 is a USB-to-UART serial converter which enables USB connectivity in applications that have a UART interface. The device reduces external components by integrating the USB termination resistors. The MCP2200 also has 256 bytes of integrated user EEPROM. The MCP2200 has eight general purpose input/output pins. Four of the pins have alternate functions to indicate USB and communication status.



MCP2210 – USB-to-SPI Protocol Converter with GPIO (Master Mode)

The MCP2210 device is a USB-to-SPI Master converter which enables USB connectivityin applications that have an SPI interface. The device reduces external components by integrating the USB termination resistors. The MCP2210 also has 256 bytes of integrated user EEPROM. The MCP2210 has nine general purpose input/output pins. Seven pins have alternate functions to indicate USB and communication status.



MCP2221 – USB-to-UART/I2C Serial Converter

The MCP2221 is a USB-to-UART/I2C serial converter which enables USB connectivity in applications that have a UART and I2C interfaces. The device reduces external components by integrating the USB termination resistors and the oscillator needed for USB operation. The MCP2221 also has four GP pins providing miscellaneous functionalities (GPIO, USBCFG, SSPND, Clock Output, ADC, DAC, interrupt detector).





Feature

MCP2200

MCP2210

MCP2221

USB Speed

Full Speed(12Mbps)

Full Speed(12Mbps)

Full Speed(12Mbps)

USB Connectivity

USB2.0

USB2.0

USB2.0

MCU Interface

UART

SPI

I2CTM/UART/SMBus

Recommended UART Rate (max.)

1Mbps

N/A

115.2kpps

Hardware Flow Control Pin

Yes

N/A

No

UART Pin Polarity Inversion Capable

Yes

N/A

No

Internal Oscillator

No

No

Yes

TX Buffer Size (Bytes)

128

64

64

RX Buffer Size (Bytes)

128

64

64

GPIO Pins

8

9

4

256Bytes

Yes

Yes

No

ADC/DAC Peripheral

No

No

Yes

Operating Temperature Range

-40°C to +85°C

-40°C to +85°C

-40°C to +85°C

Package Options

20-lead QFN, SOIC, SSOP

20-lead QFN, SOIC, SSOP

14-lead PDIP, SOIC, TSSOP, 16-lead QFN

Development boards

MCP2200 Breakout Module - Part Number: ADM00393

MCP2200 USB to RS232 Demo Board -Part Number: MCP2200EV-VCP

MCP2210 Evaluation Kit - Part Number: ADM00421

MCP2210 Breakout Module - Part Number: ADM00419

MCP2221 Breakout Module - Part Number: ADM00559





Search in catalog





Search in catalog



Ask us



AVAILABLE SOFTWARE:

  • MCP2200/MCP2221 Mac Driver
  • MCP2200 Coniguration Utility v1.3.1
  • MCP2200 Production Utility v1.1
  • MCP2200 User DLL2014-10-10
  • MCP2200/MCP2221 Linux®Driver Information
  • MCP2200/MCP2221 Windows®Driver&Installer
